SDA08H0SB by littelfuse/c-k
Image is representational - see mfr. specs

SDA08H0SB

Littelfuse/C&K

Low Profile DIP ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

SDA08H0SB is an 8-position low-profile DIP switch from the SDA Series, featuring a flush actuator design with surface mount (gull wing) terminals and a peelable top tape seal. The switch is rated for 25 mA @ 24 V DC or 100 mA @ 5 V DC, with a contact resistance of 50 mO maximum and an insulation resistance of 100 MO between terminals. It offers mechanical and electrical life of 1,000 cycles at rated loads, operates over a temperature range of -40°C to +85°C, and features a dielectric withstanding voltage of 300 V DC minimum for 1 minute. The switch has a length (DIM 'A') of 0.876 inches (22.26 mm) and a travel distance of 0.051 inches (1.30 mm), with an operating force of 800 grams maximum. This switch is ideal for address switching in industrial controls, logic switching for computers and peripherals, and general function control applications where space-saving and reliable switching are required.

Search Keywords: SDA08H0SB

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
SDA08H0SB
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
TUBE
Body Orientation:
Straight
Actuator Style:
Flush Slide
Actuator Length:
0 mm
Number of Positions:
8
Pole Throw Configuration:
SPST
Mounting:
Surface Mount
Terminal Type:
Gull Wing
Contact Rating @ Voltage:
0.1@5VDC A
Contact Plating:
Gold
Terminal Pitch:
2.54 mm

IN STOCK: 3,450

Can Ship immediately

MOQ for In Stock Qty: 10

MOQ for out of Stock Qty: 300

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
10
$3.15
50
$2.16
100
$2.14
300
$2.07
600
$2.01
900
$1.98
1,200 +
$1.94
