T101MH9ABE by littelfuse/c-k
Image is representational - see mfr. specs

T101MH9ABE

Littelfuse/C&K

Subminiature Toggle Switch ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

T101MH9ABE is a subminiature toggle switch from the C&K T Series, designed for compact switching applications. This single-pole double-throw (SPDT) switch features an ON-NONE-ON function with connected terminals 2-3 in position 1 and 2-1 in position 3. It offers a contact rating of 2 AMPS @ 120 V AC or 28 V DC, contact resistance below 20 mO typical, and insulation resistance of 10? O minimum. The switch operates over a temperature range of -30°C to 85°C with an electrical life of 30,000 make-and-break cycles at full load. Typical applications include hand-held telecommunications, instrumentation, and medical equipment where compact size and reliable switching are required.

Search Keywords: T101MH9ABE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
T101MH9ABE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
200
Package Type:
BULK
Pole Throw Configuration:
1P2T (SPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
0.4@20VAC 20VDC A
Actuator Style:
Round Lever
Mounting:
PC Mount with Bracket
Thread Size:
N/R
Body Orientation:
Right Angle
Terminal Type:
PC Pins
Operating Temperature:
-30 to 85 °C

IN STOCK: 949

Ships today, if you order in

On Order: 600   can ship 7/15/26

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$10.56
25
$8.59
50
$8.51
200
$8.43
400
$8.37
600
$8.23
1,000 +
$7.94
Suppliers Standard Package
