U21SYZGE by littelfuse/c-k
Image is representational - see mfr. specs

U21SYZGE

Littelfuse/C&K

Switch Toggle ON None ON DPDT Round Lever Solder Lug 5A 250VAC 28VDC 0.4VA Panel Mount with Threads Bulk ...

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

U21SYZGE is a miniature DPDT (Double Pole Double Throw) toggle switch from the C&K 7000 Series, designed for multi-position switching applications. This switch features an ON-NONE-ON switch function with 3 positions, epoxy terminal seal compatible with bottom wash cleaning, and a 1/4-40 UNS-2A threaded bushing. Key electrical specifications include contact resistance below 10 mO typical, insulation resistance of 10?O minimum, dielectric strength of 1000 Vrms minimum at sea level, and an operating temperature range of -30°C to 85°C. The switch provides 40,000 cycles of electrical life and is commonly used in telecommunications, instrumentation, and medical equipment applications where reliable multi-pole switching is required.

Search Keywords: U21SYZGE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Littelfuse/C&K
Part No:
U21SYZGE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
853650
COO:
VN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BULK
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
0.4@20VAC 20VDC A
Actuator Style:
Round Lever
Mounting:
Panel Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
12.7 x 11.43 x 32.39 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 52

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 25

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
5
$15.79
10
$13.79
25
$13.66
50
$12.77
75
$12.37
100 +
$12.25
Suppliers Standard Package
