SSF-LXH100YD-01 by lumex
Image is representational - see mfr. specs

SSF-LXH100YD-01

Lumex

The SSF-LXH100YD-01 is a T-5 yellow diffused LED configured as a right-angle fault indicator. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The SSF-LXH100YD-01 is a right-angle fault indicator featuring a T-5 yellow diffused LED. It emits light at a peak wavelength of 585 nm with a typical axial intensity of 30 mcd at a forward current of 20mA. This component has a 60-degree viewing angle, a typical forward voltage of 2.1V, and a minimum reverse voltage of 5.0V. Designed for reliable performance, it operates over a temperature range of -40°C to +85°C with a maximum steady forward current of 30 mA. This through-hole indicator is ideal for board-level status indication in various electronic devices.

Search Keywords: SSFLXH100YD01

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Lumex
Part No:
SSF-LXH100YD-01
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541410000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Dominant Wavelength:
N/A
Color:
Yellow
Color Temperature:
N/A
Category:
Standard LED
Dimension:
6 x 13.7 x 6 mm

IN STOCK: 4,381

Can Ship immediately

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
500
$0.3792
1,000
$0.3319
2,500
$0.2905
5,000
$0.2890
7,500
$0.2876
25,000
$0.2743
50,000 +
$0.2730
Suppliers Standard Package
