PF-27N25WQ by mallory sonalert
Image is representational - see manufacturer specifications
Mallory Sonalert Authorized Distributor

PF-27N25WQ

The PF-27N25WQ is a panel-mount audio indicator that produces a fast pulsed tone at a frequency of 2500 Hz. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PF-27N25WQ is an electronic audio indicator designed to provide a clear audible signal. It operates over a wide voltage range of 3 to 28 VDC, with a rated voltage of 12 VDC, and produces a minimum sound pressure level of 90 dB at 30 cm. This device features an oscillation frequency of 2500 ±500 Hz and a fast pulse rate of 3.0 Hz, while consuming a maximum of 15 mA at its rated voltage. Housed in black ABS plastic and equipped with 28 AWG lead wires, it is built to function reliably in temperatures from -20°C to +70°C. The PF-27N25WQ is suitable for various applications requiring a distinct audible alert, such as in control panels, alarm systems, and electronic equipment.

Search Keywords: PF27N25WQ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Mallory Sonalert
Part No:
PF-27N25WQ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8531809041
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Minimum Operating Supply Voltage:
3 VDC
Maximum Operating Supply Voltage:
28 VDC
Termination Method:
Wire Lead
Minimum Sound Pressure:
90 dBA
Mounting:
Flange Mount

IN STOCK: 166

Can Ship immediately

Manufacturer Stock: 30   can ship 12/7/26

Minimum Order Quantity: 5

Factory Lead-Time 24 Weeks can ship 5/10/27

Price (USD)

Qty
Unit Price
5
$18.94
25
$10.79
50
$9.81
100
$8.78
250
$8.02
500
$7.58
1,000 +
$7.30
