SC628AN by mallory sonalert
Image is representational - see manufacturer specifications
Mallory Sonalert Authorized Distributor

SC628AN

Audio 6VAC 28VAC 30mA 88dBA 2400Hz to 3400Hz Screw Panel Mount ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The SC628AN is a loud continuous-duty AC audible alarm designed for industrial and commercial signaling applications. It operates on 6 to 28 VAC with a current draw of 4–30 mA and produces a sound output of 88 to 101 dB(A) at 2 feet at a frequency of 2900 ± 500 Hz. The device features a molded black nylon housing and is rated for operating temperatures from -30 °C to +65 °C and storage temperatures from -40 °C to +85 °C. It mounts directly to panels via a 1.25-inch hole with a knurled nut (maximum torque 10 in-lbs) and includes brass tin-plated terminals tapped for #6-32 screws that accept 1/4-inch quick-connect terminals. The SC628AN is ideal for alarm systems, warning signals, and notification applications requiring a compact, durable, and high-output audible indicator.

Search Keywords: SC628AN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Mallory Sonalert
Part No:
SC628AN
Unit of Measure:
Per Each
RoHS:
No
HTS:
8531809041
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Minimum Sound Pressure:
88 dBA
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 43

Ships today, if you order in

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
1
$52.17
5
$36.50
10
$36.14
25
$34.93
50
$33.02
100
$31.99
250 +
$31.92
Log in for special pricing

Tools/3D Models

Product Guides
