1403404 by marathon special products
Image is representational - see manufacturer specifications
Marathon Special Products Authorized Distributor

1403404

Conn Power Distribution Blocks 3 POS Screw Cable Mount 310A ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1403404 is a power terminal block designed for high-current industrial power distribution applications, rated for 310 amps at 600 volts AC/DC. It accommodates line-side conductors from 350 kcmil to #6 AWG and load-side conductors from #4 to #14 AWG, with a connector terminal rating of 75°C for both copper and aluminum wire. The block features a phenolic insulator base with UL94V0 flammability rating and operates across a temperature range of -40°C to +150°C (UL RTI). It is UL recognized (UL 1059, File No. XCFR2.E62806), CSA certified (C22.2 No. 158), and CE compliant to IEC 60947-7-1, with short circuit current ratings up to 100,000 A RMS symmetrical at 600V depending on conductor and fuse class combinations. This terminal block is ideal for power distribution panels, motor control centers, and industrial switchgear where reliable high-current connections and multi-wire termination are required.

Search Keywords: 1403404

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Marathon Special Products
Part No:
1403404
Unit of Measure:
Per Each
RoHS:
Yes
COO:
US
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Type:
Power Distribution Blocks
Mounting:
Cable Mount
Gender:
N/A
Termination Method:
Screw
Pitch:
N/A
Number of Circuits:
3
Maximum Voltage Rating:
600,600 VDC|VAC
Maximum Current Rating:
310 A
Wire Size:
(6.2/0)-6 AWG
Operating Temperature:
N/A

IN STOCK: 0

On Order: 24   can ship 3/15/27

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
1
$283.65
3
$275.76
5
$275.08
10
$271.99
20 +
$264.74
Log in for special pricing

Tools/3D Models

Product Guides
