26TB08F by marathon special products
Image is representational - see mfr. specs

26TB08F

Marathon Special Products

The 26TB08F is an 8-pole, double-row, Navy Class terminal board rated for 20A and 300V RMS. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 26TB08F is a double-stud, double-row Navy Class terminal board designed for robust electrical connections. It features 8 poles, providing 8 terminals with the included stud connectors or 16 terminals without them. The board is rated for 20A at 60Hz and 300V RMS, with a dielectric withstanding voltage of 1500V RMS. Constructed with a MAI-60 insulator base that has a UL 94V-0 flammability rating, it can operate at a maximum temperature of 130°C. This terminal board is suitable for use with copper wire up to #16 AWG and is ideal for applications requiring durable and reliable terminations that conform to A-A-59125 / 24 standards.

Search Keywords: 26TB08F

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Marathon Special Products
Part No:
26TB08F
Alias/AKA:
0824014
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536908585
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Type:
Navy Class Terminal Blocks
Mounting:
Cable Mount
Gender:
N/A
Termination Method:
N/A
Pitch:
7.9 mm
Number of Circuits:
8
Maximum Voltage Rating:
300 VAC
Maximum Current Rating:
20 A
Wire Size:
16 AWG
Operating Temperature:
130(Max) °C

IN STOCK: 3

Can Ship immediately

On Order: 25   can ship 7/16/26

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$246.08
3
$227.35
5
$209.16
10
$176.13
20 +
$175.25
Log in for special pricing Click for Quote Price Match Request
