DDR-15L-24 by mean well
Image is representational - see mfr. specs

DDR-15L-24

MEAN WELL

The DDR-15L-24 is a 15W DIN rail mountable DC-DC converter that provides a regulated 24V output. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The DDR-15L-24 is a 15W DIN Rail type DC-DC converter from the DDR-15 series. It accepts a wide 4:1 input voltage range of 18V to 75Vdc and delivers a nominal 24Vdc output with a rated current of 0.63A. This model features a high typical efficiency of 87%, an adjustable output voltage range of 21.6V to 28V, and 4KVdc I/O isolation. It is equipped with protections for short circuit, overload, over voltage, input reverse polarity, and input under voltage. With its ultra-slim 17.5mm width and wide operating temperature of -40 to +85°C, it is ideal for industrial control systems, factory automation, and telecommunication systems.

Search Keywords: DDR15L24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
MEAN WELL
Part No:
DDR-15L-24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409580
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Dimension:
58.4 x 17.5 x 90 mm
Input Voltage:
18 to 75 V
Family:
DDR-15G

IN STOCK: 97

Can Ship immediately

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$20.70
5
$19.80
10
$18.80
20 +
$18.30
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides
