HLG-120H-24B by mean well

HLG-120H-24B

Mean Well

AC/DC LED Power Supply – 24VDC - 120W-5A- Constant Current/Constant Voltage – Input from 90 to 305VAC – 3 in 1 dimming adjustable via potentiometer. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HLG-120H-24B is a 120W AC/DC LED driver featuring a dual mode constant voltage and constant current output. HLG-120H-24B operates from 90 to 305VAC. Voltage output is 24 VDC and constant output current region from 12-24VDC with rated current of 5A. Thanks to the high efficiency up to 93%,with the fanless design, it is able to operate from -40℃ ~ +80℃ case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG-100H-36B is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system. The HLG-120H-24B has a typical lifetime of 62000 hours and a 7-year factory warranty.

Search Keywords: HLG120H24B

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
HLG-120H-24B
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Fixed, Dimmable
Dimming:
1 to 10 Vdc/PWM/Resistance
Maximum Output Power:
120 W
Output Voltage Range:
12.0 to 24.0 Vdc
Maximum Output Current:
5,000 mA (5.0 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 80 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, EAC, ENEC 17, PSE, RCM, TUV
IEC Class:
I
SELV:
Yes
LPS:
No
Warranty:
7 Years
Family:
HLG-120H

IN STOCK: 180

Can Ship immediately

Factory Lead-Time 16 Weeks

Price (CAD)

Qty
Unit Price
1
$83.150
5
$79.321
10
$75.799
20 +
$73.502
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
