HLG-320H-36A by mean well
Image is representational - see manufacturer specifications
MEAN WELL Authorized Distributor

HLG-320H-36A

AC/DC LED Power Sply - Const Curr/Volt - 320.4W - Adj: 36 Vdc @ 8,900mA - Dim: No ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC; Output 36Vdc at 8.9A; IP65; Cable output; Dimming with Potentiometer. It has an output power of 320.4W, and can work up to 90°C temperature. Width, height and depth is 68 mm, 38.8 mm, and 220 mm respectively.

Search Keywords: HLG320H36A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
MEAN WELL
Part No:
HLG-320H-36A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409530
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC8097
Style:
Enclosed
Type:
Constant Current/Voltage
Output Type:
Adjustable
Dimming:
No
Maximum Output Power:
320 W
Output Voltage Range:
18.0 to 36.0 Vdc
Maximum Output Current:
8,900 mA (8.9 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 90 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, PSE, RCM, TUV
IEC Class:
None
SELV:
Yes
LPS:
No
Warranty:
7 Years
Family:
HLG-320H

IN STOCK: 64

Ships today, if you order in

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$107.39
5
$100.53
10
$97.57
20
$94.63
50 +
$90.72
