HLG-600H-24A by mean well
Image is representational - see manufacturer specifications

HLG-600H-24A

MEAN WELL

AC/DC LED Pwr Sply - Const Volt - 600W - Adj: 24 Vdc @ 25,000mA (25.0 A) - Dim: No

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AC-DC Single output LED driver Mix mode (CV+CC) with built-in PFC; Output 24Vdc at 25A; IP65; Cable output; CC/CV adjustable with potentimeter. It has an output power of 600W.Width, height and depth is 144 mm, 48.5 mm, and 280 mm respectively.

Search Keywords: HLG600H24A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
MEAN WELL
Part No:
HLG-600H-24A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409510
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Style:
Enclosed
Type:
Constant Voltage
Output Type:
Adjustable
Dimming:
No
Maximum Output Power:
600 W
Output Voltage Range:
20.4 to 25.2 VDC
Maximum Output Current:
25,000 mA (25.0 A)
Minimum AC Input Voltage:
90
Maximum AC Input Voltage:
305
Minimum DC Input Voltage:
127
Maximum DC Input Voltage:
431
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 70 °C
Safety Agency Approvals:
CB, CCC, CE, cRUus, EAC, ENEC 17, PSE, RCM
IEC Class:
I
SELV:
Yes
LPS:
No
Warranty:
5 Years
Family:
HLG-600H

IN STOCK: 241

Ships today, if you order in

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
1
$211.40
5
$201.40
10
$192.40
20 +
$186.80
Log in for special pricing Click for Quote Price Match Request
