HVG-240-54B by mean well
Image is representational - see mfr. specs

HVG-240-54B

MEAN WELL

The HVG-240-54B is a 240W AC/DC LED driver featuring a dual-mode constant voltage (54V) and constant current (4.5A) output with 3-in-1 dimming. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HVG-240-54B is a 243W AC/DC LED power supply featuring a dual-mode constant voltage and constant current output. It operates over a wide input range of 180 to 528VAC and delivers a rated output of 54V at 4.5A within a constant current region of 27V to 54V. As a B-type model, it includes 3-in-1 dimming functionality (0-10VDC, 10V PWM, or resistance) and is enclosed in a metal housing with an IP67 rating for robust indoor or outdoor use. With high efficiency up to 93% and a built-in active PFC function, this fanless driver is designed for reliability in harsh environments. Common applications include LED street lighting, high-bay lighting, parking space lighting, and greenhouse lighting.

Search Keywords: HVG24054B

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
MEAN WELL
Part No:
HVG-240-54B
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504409530
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
AC/DC
Style:
Enclosed
Type:
Constant Current
Output Type:
Fixed, Dimmable
Dimming:
0 to 10 Vdc/PWM/Resistance
Maximum Output Power:
243 W
Output Voltage Range:
50.0 to 57.0 Vdc
Maximum Output Current:
4,500 mA (4.5 A)
Minimum AC Input Voltage:
180
Maximum AC Input Voltage:
528
Minimum DC Input Voltage:
254
Maximum DC Input Voltage:
747
Termination Style:
Wire Leads
Input Connector Type:
Stripped and Tinned
Output Connector Type:
Stripped and Tinned
Operating Temperature:
-40 to 70 °C
Safety Agency Approvals:
cRUus
IEC Class:
I
SELV:
No
LPS:
No
Warranty:
5 Years
Family:
HVG-240

IN STOCK: 4

Can Ship immediately

On Order: 12   can ship 5/25/26

Factory Lead-Time 16 Weeks
