LDD-700L by mean well

LDD-700L

Mean Well

DC-DC Step down LED driver Constant Current (CC); Input 9-36Vdc; Output 0.7A at 2-32Vdc; PCB through hole; Dimming with PWM and remote ON/OFF ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The LDD-700L is a 22W DC-DC Constant Current Step-Down LED driver. LDD-700L has wide input voltage from 6 to 36 VDC. Voltage output will always step down by 3V from input DC voltage and has wide output LED string voltage from 2 to 32VDC at constant current output 700mA. Thanks to the high efficiency up to 95%, it is able of operating from -40 to +85 ℃ case temperature under free air convection. The IP67 design ingress protection level allows this component to be suitable for driving illumination LED.The LDD-700L has built in EMI filter and PWM dimming with remote ON/OFF control. The LDD-700L has a 3 years factory warranty.

Search Keywords: LDD700L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Mean Well
Part No:
LDD-700L
RoHS:
Yes
HTS:
8504409580
COO:
Tw
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Input/Output Type:
DC/DC
Style:
Module
Type:
Constant Current
Output Type:
Fixed, Dimmable
Dimming:
PWM
Maximum Output Power:
Not Specified
Output Voltage Range:
2 to 32 VDC
Maximum Output Current:
700 mA (0.7 A)
Minimum AC Input Voltage:
Not App
Maximum AC Input Voltage:
Not App
Minimum DC Input Voltage:
9
Maximum DC Input Voltage:
36
Termination Style:
Pin
Input Connector Type:
PC Pins
Output Connector Type:
PC Pins
Operating Temperature:
-40 to 85 °C
Safety Agency Approvals:
CE
IEC Class:
None
SELV:
No
LPS:
No
Warranty:
3 Years
Family:
LDD-700L

IN STOCK: 1,024

Ships today, if you order in

Factory Lead-Time 16 Weeks

Price (CAD)

Qty
Unit Price
1
$5.724
10
$5.438
20
$5.166
50 +
$4.908
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
