PD-25B

Name: PD-25B
Brand: Mean Well
SKU: 11952662
Price: 16.27 USD
Availability: InStock

AC-DC Dual output Open frame Power supply; Output 5Vdc at 2A +24Vdc at 1A ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The PD-25B is a 25.2W Dual Output Switching Power Supply. PD-25B operates from 85 to 264VAC. Voltage output is for channel 1 is 5V at rated current 1.2A and for channel 2 is 24V at rated current .8A . Thanks to the high efficiency up to 77%, it is able of operating from -10 to +60 ℃ case temperature under free air convection. The PD-25B uses different protection techniques such as short circuit/over load /over voltage/ over temperature with low leakage current <.5mA. The PD-25B has a 2 years factory warranty.

Product Highlights:

Potential Applications:

Search Keywords: PD25B

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

MEAN WELL

Part No:

PD-25B

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504409510

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
