RPD-60B

Name: RPD-60B
Brand: Mean Well
SKU: 11952945
Availability: InStock

The RPD-60B is a 53.5W dual-output medical grade PCB-type power supply with 5V and 24V outputs. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The RPD-60B is a 53.5W dual-output, PCB-type medical power supply designed for reliable performance in a compact 4" by 2" footprint. It provides a primary 5V output channel with a rated current of 3.5A and a secondary 24V channel with a rated current of 1.5A. The power supply operates with a high typical efficiency of 82% and accepts a universal AC input from 90V to 264V. It features built-in protections for overload, over-voltage on the primary channel, and short circuits. With its extremely low leakage current and medical safety approvals (2xMOPP), it is suitable for body-floating (BF) applications such as hemodialysis machines and sleep apnea devices.

Product Highlights:

Potential Applications:

Search Keywords: RPD60B

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

MEAN WELL

Part No:

RPD-60B

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504409510

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
