SGA12E05-USB

Products found: 0

Supplier:

MEAN WELL

Part No:

SGA12E05-USB

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504409510

COO:

Tw

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

1

Input/Output Type:

AC/DC

Type:

Regulated-Switching

Style:

WallMount

Output Type:

Fixed

Number of Outputs:

1

Power:

12 W

Output Voltage:

5 VDC

Output Current:

2.4 A

Ripple & Noise:

50 mV

Grade:

Commercial

MOPP:

Not App

DOE Efficiency Level:

VI

CoC Tier:

No

Safety Class:

II

Safety Approvals:

CB, CE, EAC, GS, TUV

Efficiency:

80(Typ) %

Output Connector Type:

USB - A Jack

Output Connector Polarity:

Not App

Output Connector Diameters:

Not App

Output Connector Angle:

Straight

Output Cord Length:

Not App

AC Input Voltage:

90 to 264

Minimum AC Input Voltage:

90

Maximum AC Input Voltage:

264

Input Frequency:

47 to 63 Hz

Line Regulation:

1.00 %

Load Regulation:

5.00 %

Overload Protection:

Yes

Over Voltage Protection:

Yes

Short Circuit Protection:

No

Thermal Protection:

No

Operating Temperature:

-20 to 60 °C

Power Indicator:

No

Minimum Load (Amps):

0

Minimum Isolation Voltage:

4242Vdc

Input Connector Type:

EU Blades

Dimensions L x W x H:

62.2 x 27.4 x 39.7 mm

Dimensions L x W x H(in):

2.45 x 1.08 x 1.57 in

Life Cycle:

Discontinued & Replaced
