ATF16V8BQL-15SU by microchip technology

ATF16V8BQL-15SU

Microchip Technology

SPLD ATF16V8B Family 250 Gates 8 Macro Cells 62MHz 5V 20-Pin SOIC W Tube ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The ATF16V8BQL-15SU is a high-performance SPLD (Simple Programmable Logic Device) from the ATF16V8B family by Microchip Technology. It offers a total of 250 gates with 8 macro cells, providing ample configurability for various applications. This SPLD operates at a frequency of up to 62MHz, making it suitable for fast-paced systems. With a voltage rating of 5V, it ensures compatibility with a wide range of devices. The ATF16V8BQL-15SU is presented in a 20-pin SOIC package, conveniently supplied in a protective tube for easy handling and storage.

Search Keywords: ATF16V8BQL15SU

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
ATF16V8BQL-15SU
RoHS:
Yes
HTS:
8542310055
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
37
Package Type:
TUBE
In-System Programmability:
No
Family Name:
ATF16V8B
Device System Gates:
250
Maximum Operating Current:
20(Typ) mA
Fabrication Technology:
N/A
Dimension:
13(Max) x 7.6(Max) x 2.37(Max) mm
Maximum Internal Frequency:
62 MHz
Family:
ATF16V8BQL
Maximum Number of User I/Os:
8
Maximum Operating Supply Voltage:
5.5 V

IN STOCK: 649

Can Ship immediately

Manufacturer Stock: 747   can ship 12/5/25

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 195

Factory Lead-Time 16 Weeks can ship 3/13/26

Price (CAD)

Qty
Unit Price
25
$2.151
50
$2.118
100
$2.086
195
$2.055
389
$1.545
583
$1.444
777 +
$1.415
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
