LAN9500AI-ABZJ by microchip technology
Image is representational - see manufacturer specifications
Microchip Technology Authorized Distributor

LAN9500AI-ABZJ

Ethernet Controller - 10Mbps/100Mbps - 3.3V - 56-Pin. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The LAN9500AI-ABZJ is a high-performance Hi-speed USB 2.0 to 10/100 Ethernet Controller contains an integrated 10/100 Ethernet PHY, USB PHY, Hi-speed USB 2.0 device controller, 10/100 Ethernet MAC, TAP controller, EEPROM controller and a FIFO controller with a total of 30kB of internal packet buffering. The internal USB 2.0 device controller and USB PHY are compliant with the USB 2.0 Hi-Speed standard. The device implements control, interrupt, bulk-in and bulk-out USB endpoints. The Ethernet controller supports auto-negotiation, auto-polarity correction, HP Auto-MDIX and is compliant with the IEEE 802.3 and IEEE 802.3u standards. An external MII interface provides support for an external Fast Ethernet PHY, HomePNA and HomePlug functionality. Multiple power management features are provided, including various low power modes and "Magic Packet", "Wake On LAN" and "Link Status Change" wake events. These wake events can be programmed to initiate an USB remote wakeup.

Search Keywords: LAN9500AIABZJ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
LAN9500AI-ABZJ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542310030
COO:
SG
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
260
Package Type:
TRAY
Dimension:
8 x 8 x 0.8315276mmmm
  Different packaging options available.  See Alternatives

IN STOCK: 652

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 28 Weeks

Price (USD)

Qty
Unit Price
5
$6.79
25
$6.56
50
$6.50
100
$6.45
260
$6.42
520
$6.41
1,040
$6.39
2,600 +
$6.38
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
