LAN9514I-JZX by microchip technology

LAN9514I-JZX

Microchip Technology

Ethernet Controller - 10Mbps/100Mbps - 3.3V - 64-Pin. ...

Datasheet
RoHS Compliant
TRAY Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The LAN9514I-JZX is a high performance Hi-speed USB 2.0 Hub with a 10/100 Ethernet controller. It contains an integrated USB 2.0 hub, four integrated downstream USB 2.0 PHYs, an integrated upstream USB 2.0 PHY, a 10/100 Ethernet PHY, a 10/100 Ethernet Controller, a TAP controller and an EEPROM controller. The downstream ports of the LAN9514i hub can be reordered or disabled in any sequence to support multiple platform designs’ with minimum effort. For any port that is disabled, it automatically reorders the remaining ports to match the USB host controller’s port numbering scheme. The integrated USB hub is fully compliant with the USB 2.0 Specification and will attach to an USB host as a full-speed hub or as a full-/high-speed hub. The hub supports low-speed, full-speed and high-speed (if operating as a High-Speed hub) downstream devices on all of the enabled downstream ports.

Search Keywords: LAN9514IJZX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
LAN9514I-JZX
RoHS:
Yes
HTS:
8542310030
COO:
SG
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
260
Package Type:
TRAY
Communication Mode:
Full Duplex,Half Duplex
Data Rate:
10,100 Mbps
Category:
Single Chip
Dimension:
9 x 9 x 0.83 mm
Auto-Negotiation:
Yes

IN STOCK: 1,147

Ships today, if you order in

Manufacturer Stock: 20,455   can ship 12/5/25

Minimum Order: 5

Factory Lead-Time 4 Weeks can ship 12/18/25

Price (USD)

Qty
Unit Price
5
$10.465
25
$8.395
50
$8.302
100
$7.519
260
$7.478
520
$7.437
1,040 +
$7.406
