MCP1501T-30E/CHY by microchip technology

MCP1501T-30E/CHY

Microchip Technology

V-Ref Precision 3V 20mA 6-Pin SOT-23 T/R ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MICROCHIP TECH. MCP1501T-30E/CHY is a high-precision voltage reference designed for applications requiring accurate and stable voltage references. It provides a 3V output with a current drive capability of 20mA, making it suitable for a wide range of applications.This voltage reference is housed in a compact 6-pin SOT-23 package, allowing for easy integration into space-constrained designs. It is available in tape and reel packaging, enabling efficient automated assembly.With its excellent accuracy and stability, the MCP1501T-30E/CHY ensures precise voltage reference performance, making it ideal for use in precision measurement systems, data acquisition systems, and other applications where reliable and accurate voltage references are crucial.

Search Keywords: MCP1501T30ECHY

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP1501T-30E/CHY
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
REEL
Maximum Temperature Coefficient:
50 ppm/°C
Dimension:
3.1(Max) x 1.8(Max) x 1.3(Max) mm
Load Regulation:
70 ppm/ mA
Maximum Output Current:
20 mA
Initial Accuracy:
0.1 %
Line Regulation:
50 ppm/V
Family:
MCP1501
Mounting:
Surface Mount
Maximum Input Voltage:
5.5 V

IN STOCK: 0

On Order: 7,000   can ship 12/15/25

Minimum Order: 500

Factory Lead-Time 8 Weeks

Price (CAD)

Qty
Unit Price
500
$0.871
1,000
$0.867
3,000
$0.862
6,000
$0.858
9,000
$0.853
12,000 +
$0.850
Suppliers Standard Package
