MCP1700T-3302E/TT by microchip technology

MCP1700T-3302E/TT

Microchip Technology

Fixed LDO Voltage Regulator - 2.3V to 6V - 178mV Dropout - 3.3Vout - 250mAout. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MCP1700 is a CMOS low dropout positive voltage regulator which can source up to 250mA of current with an extremely low input-output voltage differential of 178mV at 250mA. The low dropout voltage combined with the low current consumption of only 1.6µA makes this part ideal for battery operation. The low voltage differential (dropout voltage) extends battery operating lifetime. The MCP1700 is stable with 1.0µF ceramic output capacitor. It also permits high currents in small packages when operated with minimum VIN – VOUT differentials. The circuit also incorporates short-circuit protection & over temperature protection to ensure maximum reliability.

Search Keywords: MCP1700T3302ETT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP1700T-3302E/TT
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
REEL
Function:
LDO
Junction to Ambient:
336(Typ) °C/W
Family:
MCP1700
Accuracy:
±2 %
Dimension:
2.9 x 1.3 x 0.95 mm
Junction to Case:
N/A
Maximum Dropout Voltage @ Current:
0.35@250mA V
Load Regulation:
1(Typ) %
Line Regulation:
0.75(Typ) %/V

IN STOCK: 17,000

Ships today, if you order in

Minimum Order: 3000

Multiple: 3000

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
3,000
$0.583
6,000
$0.580
9,000
$0.577
12,000
$0.574
15,000
$0.571
27,000 +
$0.568
