MCP1703T-3302E/MB by microchip technology
Image is representational - see manufacturer specifications
Microchip Technology Authorized Distributor

MCP1703T-3302E/MB

Fixed LDO Voltage Regulator - 2.7V to 16V - 525mV Dropout - 3.3Vout - 250mAout - SOT-89-3 - 4-Pin(3+Tab). ...

View Datasheet Ask the Datasheet
RoHS Compliant
REEL Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MCP1703T-3302E/MB is a CMOS low dropout Voltage Regulator that can deliver up to 250mA of current while consuming only 2μA of quiescent current (typical). The input operating range is specified from 2.7 to 16V, making it an ideal choice for two to six primary cell battery-powered applications, 9V alkaline and one or two cell Li-ion-powered applications. It is capable of delivering 250mA with only 625mV (typical) of input to output voltage differential (VOUT = 2.8V). The output voltage tolerance of the MCP1703 is typically ±0.4% at +25°C and ±3% maximum over the operating junction temperature range of -40 to 125°C. Line regulation is ±0.1% typical at +25°C. Output voltages for the MCP1703 range from 1.2 to 5.5V. The LDO output is stable when using only 1μF of output capacitance. Ceramic, tantalum or aluminium electrolytic capacitors can all be used for input and output.

Search Keywords: MCP1703T3302EMB

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP1703T-3302E/MB
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390090
COO:
TW
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
REEL
Junction to Ambient:
153.3(Typ) °C/W
Line Regulation:
0.1(Typ) %/V
Accuracy:
±2 %
Dimension:
4.6(Max) x 2.6(Max) x 1.6(Max) mm
Maximum Dropout Voltage @ Current:
0.725@250mA V
Family:
MCP1703
Junction to Case:
100(Typ) °C/W
Function:
LDO
Load Regulation:
1(Typ) %

IN STOCK: 4,000

Ships today, if you order in

Manufacturer Stock: 228,703   can ship 8/10/26

Minimum Order Quantity: 500

Factory Lead-Time 4 Weeks can ship 8/28/26

Price (USD)

Qty
Unit Price
500
$0.763
1,000
$0.757
3,000
$0.754
5,000
$0.752
8,000
$0.750
10,000
$0.748
15,000
$0.746
25,000 +
$0.745
Reel Package
