MCP3422A0-E/SN by microchip technology

MCP3422A0-E/SN

Microchip Technology

ADC - Delta Sigma - 18 bit - 3.75 SPS - Differential - I2C - Single - 2.7 V - 8-Pin. ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MCP3422A0-E/SN is a 2-channel low-noise high accuracy delta-sigma A/D Converter with differential inputs and up to 18-bit of resolution. The on-board precision 2.048V reference voltage enables an input range of ±2.048V differentially. The device uses a two-wire I²C™ compatible serial interface and operates from a single power supply ranging from 2.7 to 5.5V. The MCP3422 device performs conversions at rates of 3.75, 15, 60 or 240 samples per second depending on user controllable configuration bit settings using the two-wire I²C™ compatible serial interface. This device has an onboard programmable gain amplifier (PGA). User can select the PGA gain of x1, x2, x4 or x8 before the analogue-to-digital conversion takes place. This allows the MCP3422 device to convert a smaller input signal with high resolution. The device has continuous and one-shot mode.

Search Keywords: MCP3422A0ESN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP3422A0-E/SN
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Dimension:
4.9 x 3.9 x 1.25(Min) mm
Category:
General Purpose
  Different packaging options available.  See Alternatives

IN STOCK: 1,837

Ships today, if you order in

Manufacturer Stock: 3,402   can ship 12/5/25

Minimum Order: 5

Factory Lead-Time 6 Weeks can ship 1/1/26

Price (CAD)

Qty
Unit Price
5
$5.804
50
$4.716
100
$4.256
300
$4.242
500
$4.227
1,000
$4.195
2,500
$4.181
5,000 +
$4.166
Suppliers Standard Package
Log in for special pricing
Click for Quote
