MCP4021-202E/MS by microchip technology
Image is representational - see manufacturer specifications
Microchip Technology Authorized Distributor

MCP4021-202E/MS

A 6-bit, non-volatile digital potentiometer with a 2.1 kΩ resistance, 64 taps, and a simple Up/Down (U/D) serial interface. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MCP4021-202E/MS is a non-volatile, 6-bit digital potentiometer with a resistance of 2.1 kΩ, controlled via a simple Up/Down (U/D) serial interface. It features 64 taps for precise resistance adjustments and operates over a wide voltage range of 2.7V to 5.5V. The device includes Microchip's WiperLock™ technology, which secures the wiper setting in non-volatile EEPROM, and offers a power-on recall feature for the saved setting. Key characteristics include a low typical wiper resistance of 75Ω, high-voltage tolerant digital inputs up to 12.5V, and a typical -3 dB bandwidth of 4 MHz. This potentiometer is suitable for applications such as set point trimming, sensor calibration, and adjustable gain amplifier designs.

Search Keywords: MCP4021202EMS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP4021-202E/MS
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Package Type:
TUBE
Memory Type:
Non-Volatile
Minimum Dual Supply Voltage:
N/R
Minimum Single Supply Voltage:
2.7 V
Maximum Dual Supply Voltage:
N/R
Control Interface:
Serial (2-Wire)
Maximum Supply Current:
0.045(Typ) mA
Maximum Single Supply Voltage:
5.5 V
Family:
MCP4021
Digital Supply Voltage:
N/R
Dimension:
3 x 3 x 0.85 mm

IN STOCK: 800

Ships today, if you order in

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 19 Weeks

Price (USD)

Qty
Unit Price
100
$0.824
300
$0.790
500
$0.780
1,000
$0.749
2,500
$0.712
5,000
$0.711
7,500
$0.709
10,000 +
$0.703
