MCP4726A3T-E/CH by microchip technology
Image is representational - see mfr. specs

MCP4726A3T-E/CH

Microchip Technology

The MCP4726A3T-E/CH is a single-channel, 12-bit, voltage output Digital-to-Analog Converter (DAC) with nonvolatile EEPROM memory and an I2C interface. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MCP4726A3T-E/CH is a single-channel, 12-bit Digital-to-Analog Converter (DAC) featuring a buffered voltage output, nonvolatile EEPROM memory, and an I2C serial interface. It operates from a single 2.7V to 5.5V supply and provides a rail-to-rail buffered voltage output with a typical fast settling time of 6 µs. The device includes on-board nonvolatile EEPROM, allowing the DAC register and configuration settings to be saved and automatically recalled on power-up. Communication is handled via an I2C-compatible serial interface supporting modes up to 3.4 Mbps, with this specific model configured for I2C address '1100011'. Its features make it well-suited for applications such as set point or offset trimming, sensor calibration, and low-power portable instrumentation.

Search Keywords: MCP4726A3TECH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP4726A3T-E/CH
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390040
COO:
TH
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
3000
Package Type:
REEL
Digital Supply Support:
No
Architecture:
Resistor-String
Digital Interface Type:
Serial (2-Wire, I2C)
Maximum Dual Supply Voltage:
N/R
Full Scale Error:
82 LSB
Family:
MCP4726
Dimension:
3.1(Max) x 1.8(Max) x 1.3(Max) mm
Integral Nonlinearity Error:
±14.5 LSB
Converter Type:
General Purpose
Conversion Rate:
N/A

IN STOCK: 3,000

Can Ship immediately

Manufacturer Stock: 9,944   can ship 5/4/26

Minimum Order Quantity: 250

Factory Lead-Time 7 Weeks can ship 6/15/26

Price (USD)

Qty
Unit Price
250
$0.961
500
$0.947
1,000
$0.915
3,000
$0.873
6,000
$0.860
9,000 +
$0.848
Reel Package
