MCP6002T-I/MS by microchip technology
Image is representational - see mfr. specs

MCP6002T-I/MS

Microchip Technology

Dual Op Amp - Low Power - 1MHz GBP - 1.8 to 6.0 VDC - Rail to Rail I/O - 8-lead MSOP - -40°C to +85°C ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MCP6002T-I/MS is an Operational Amplifier is specifically designed for general-purpose applications. This family has a 1MHz Gain Bandwidth Product (GBWP) and 90° phase margin (typical). It also maintains 45° phase margin (typical) with a 500pF capacitive load. This family operates from a single supply voltage as low as 1.8V, while drawing 100µA (typical) quiescent current. Additionally, the MCP6002 supports rail-to-rail input and output swing, with a common mode input voltage range of VDD +300mV to VSS - 300mV. This family of op amps is designed with Microchip's advanced CMOS process. The MCP6002 family is available in the industrial and extended temperature ranges, with a power supply range of 1.8 to 6.0V.

Search Keywords: MCP6002TIMS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP6002T-I/MS
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542330001
COO:
TH
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
2500
Package Type:
REEL
Maximum Input Offset Voltage:
4.5@5.5V mV
Maximum Dual Supply Voltage:
N/R
Family:
MCP6002
Dimension:
3 x 3 x 0.85 mm
Maximum Input Bias Current:
N/A
Maximum Operating Supply Voltage:
6 V
Maximum Input Offset Current:
0.000001(Typ)@5.5V uA
Manufacturer Type:
Low Power Amplifier
  Different packaging options available.  See Alternatives

IN STOCK: 84,250

Can Ship immediately

Minimum Order Quantity: 1000

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.3146
2,500
$0.3115
5,000
$0.3099
7,500
$0.3084
10,000
$0.3068
15,000
$0.3053
25,000 +
$0.3037
Reel Package
