MCP6022-I/SN by microchip technology

MCP6022-I/SN

Microchip Technology

Operational Amplifier - Dual - 2 Amplifier - 10 MHz - 7 V/µs - 2.5V to 5.5V - 8 Pins. ...

Datasheet
RoHS Compliant
TUBE Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MCP6022 dual operational amplifier (op amp) has a gain bandwidth product of 10 MHz with a low typical operating current of 1.0 mA and an offset voltage that is less than 0.5 mV. The MCP6022 uses Microchip's advanced CMOS technology, which provides low bias current, high-speed operation, high open-loop gain, and rail-to-rail output swing. The MCP6022 operates with a single supply voltage that can be as low as 2.5V, while drawing less than 1.35 mA of quiescent current per amplifier. The MCP6022 is available in standard 8-lead PDIP, SOIC and TSSOP packages. This amplifier is ideal for battery and loop-powered applications as well as industrial process control, low-power battery-operated devices, portable equipment, data acquisition equipment, test equipment and low-end audio applications. AEC-Q100 Grade 1 qualification is available for this device.

Search Keywords: MCP6022ISN

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MCP6022-I/SN
RoHS:
Yes
HTS:
8542330001
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
TUBE
Manufacturer Type:
General Purpose Amplifier
Dimension:
4.9 x 3.9 x 1.25(Min) mm
Maximum Input Bias Current:
0.015@5.5V@85C uA
Maximum Operating Supply Voltage:
5.5 V
Maximum Dual Supply Voltage:
N/R
Family:
MCP6022
Maximum Input Offset Voltage:
0.5@5.5V mV
Maximum Input Offset Current:
0.000001(Typ)@5.5V uA
  Different packaging options available.  See Alternatives

IN STOCK: 2,200

Ships today, if you order in

Minimum Order: 100

Multiple: 100

Factory Lead-Time 5 Weeks

Price (CAD)

Qty
Unit Price
100
$2.129
300
$2.006
500
$1.976
1,000
$1.899
2,500
$1.838
5,000
$1.806
7,500 +
$1.777
Suppliers Standard Package
Log in for special pricing
Click for Quote
