MIC5233YM5-TR by microchip technology

MIC5233YM5-TR

Microchip Technology

LDO Voltage Regulator - Adjustable - 2.3 V to 36 V in - 270 mV Dropout - 1.24 V to 20 V/0.1A out - SOT-23-5 - 5-Pin. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MIC5233YM5 TR is a high input voltage low IQ µCap LDO Regulator with high input voltage and ultra-low ground current. This combination of high input voltage and low ground current makes the regulator ideal for multi-cell Li-Ion battery systems. A µCap LDO design, the regulator is stable with either ceramic or tantalum output capacitors. It only requires a 2.2µF capacitor for stability. It features an enable input, thermal shutdown, current limit, reverse battery protection and reverse leakage protection.

Search Keywords: MIC5233YM5TR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
MIC5233YM5-TR
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Package Type:
REEL
Dimension:
2.9 x 1.6 x 1.1 mm
Line Regulation:
0.5 %
Maximum Dropout Voltage @ Current:
0.3@50mA,0.4@100mA V
Junction to Ambient:
235 °C/W
Accuracy:
±1 %
Load Regulation:
1 %
Function:
LDO
Junction to Case:
N/A
Family:
MIC5233

IN STOCK: 1,390

Ships today, if you order in

Minimum Order: 250

Factory Lead-Time 9 Weeks

Price (CAD)

Qty
Unit Price
250
$1.546
500
$1.524
1,000
$1.499
3,000
$1.475
6,000 +
$1.451
