TC1262-3.3VDBTR by microchip technology

TC1262-3.3VDBTR

Microchip Technology

Fixed LDO Voltage Regulator - 2.7V to 6V - 350mV Dropout - 3.3Vout - 500mAout - SOT-223 - 4-Pin(3+Tab). ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TC1262-3.3VDBTR is a fixed output high accuracy CMOS Low Dropout Regulator (LDO) for battery-operated systems. The TC1262 is CMOS construction eliminates wasted ground current, significantly extending battery life. Total supply current is typically 80µA at full load (20 to 60 times lower than in bipolar regulators). TC1262 key features include ultra low noise, very low dropout voltage (typically 350mV at full load) and fast response to step changes in load. The TC1262 incorporates both over-temperature and over-current protection. The TC1262 is stable with an output capacitor of only 1µF and has a maximum output current of 500mA.

Search Keywords: TC126233VDBTR

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
TC1262-3.3VDBTR
RoHS:
Yes
HTS:
8542390090
COO:
TW
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
4000
Package Type:
REEL
Function:
LDO
Line Regulation:
0.003(Typ) %
Dimension:
6.5 x 3.5 x 1.6 mm
Accuracy:
±0.5 %
Load Regulation:
0.002(Typ) %
Family:
TC1262
Maximum Dropout Voltage @ Current:
0.03@100uA,0.13@100mA,0.39@300mA,0.65@500mA V
Junction to Case:
N/A
Junction to Ambient:
59 °C/W

IN STOCK: 5,885

Can Ship immediately

Manufacturer Stock: 7,035   can ship 12/5/25

Minimum Order: 500

Factory Lead-Time 7 Weeks can ship 1/8/26

Price (CAD)

Qty
Unit Price
500
$0.797
1,000
$0.792
4,000
$0.786
8,000
$0.783
12,000
$0.779
16,000
$0.776
28,000 +
$0.772
