TC962EPA by microchip technology
Image is representational - see manufacturer specifications
Microchip Technology Authorized Distributor

TC962EPA

Charge Pump INV -3V to -18V 80mA Automotive 8-Pin PDIP Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MICROCHIP TECH. TC962EPA is a versatile charge pump inverter designed for automotive applications. It can generate an inverted voltage range from -3V to -18V with a maximum output current of 80mA. This 8-pin PDIP package provides a convenient and reliable solution for power conversion in automotive electronic systems. It comes in a tube packaging for easy handling and storage. Upgrade your automotive designs with the dependable and efficient TC962EPA charge pump inverter from MICROCHIP TECH.

Search Keywords: TC962EPA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Microchip Technology
Part No:
TC962EPA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390090
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
TUBE
Operating Temperature:
-40 to 85 °C
Maximum Power Dissipation:
730 mW
Dimension:
10.16(Max) x 6.6(Max) x 4.06(Max) mm
Family:
TC962
Maximum Supply Current:
0.7 mA
Maximum Operating Supply Voltage:
18 V
Mounting:
Through Hole
Minimum Operating Supply Voltage:
3 V
Function:
Inverting
Efficiency:
97(Typ) %

IN STOCK: 600

Ships today, if you order in

Manufacturer Stock: 3,970   can ship 8/28/26

Minimum Order Quantity: 60

Multiple: 60

Factory Lead-Time 5 Weeks can ship 9/18/26

Price (USD)

Qty
Unit Price
60
$4.04
120
$3.93
300
$3.79
540
$3.69
1,020
$3.56
2,520
$3.54
5,040
$3.52
7,500 +
$3.48
Supplier's Standard Package
