PCMAS100S24

Name: PCMAS100S24
Brand: Mtm Power
SKU: 11946640
Price: 208.98 USD
Availability: InStock

The PCMAS100S24 is a 100W chassis-mount primary switching power supply that provides a regulated 24VDC, 4.0A output. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The PCMAS100S24 is a 100W primary switcher power supply designed for chassis mounting. It features a wide input range of 90-264 VAC for worldwide application, delivering a stable 24VDC output at 4.0A with an efficiency of up to 90%. The unit operates across a broad ambient temperature range of -25°C to +70°C and includes continuous short-circuit and overload protection with constant current behavior. Housed in a compact 166.0 x 85.0 x 35.0 mm case, it is ideal for decentralized power in industrial applications and as a plug-and-play power supply for sensitive electronic subsystems.

Product Highlights:

Potential Applications:

Search Keywords: PCMAS100S24

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

MTM Power

Part No:

PCMAS100S24

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8504409540

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
