NC3FAH by neutrik

NC3FAH

Neutrik

A Series - 3 pole female XLR receptacle - grounding: without ground/shell contact - horizontal PCB mount The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NC3FAH is 3 pole female XLR receptacle, grounding: without ground/shell contact, horizontal PCB mount The NC3FAH has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm between centres). New designed tulip type contacts with hard gold plating and polished contact areas. UL recognized component.

Product Highlights:

  • Smallest XLR receptacles, highest packing density
  • Plastic housing, steel latch lock
  • Tulip type female contact
  • Polished contact areas and hard gold plating
  • Housing flammability UL94V-0

Search Keywords: NC3FAH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Neutrik
Part No:
NC3FAH
RoHS:
Yes
HTS:
8536694040
COO:
LI
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide
Number of Contacts:
3
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

IN STOCK: 246

Ships today, if you order in

Manufacturer Stock: 1,600   can ship 12/1/25

Minimum Order: 100

Multiple: 100

Factory Lead-Time 3 Weeks can ship 12/11/25

Price (USD)

Qty
Unit Price
100
$1.741
300
$1.689
500
$1.679
1,000
$1.669
2,500
$1.658
5,000
$1.597
7,500 +
$1.586
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
