NC3FAH-0 by neutrik

NC3FAH-0

Neutrik

A Series - 3 pole female XLR receptacle - grounding: without ground/shell contact - horizontal PCB mount - Retention spring instead of latch The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest siz ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NC3FAH-0 is 3 pole female XLR receptacle, grounding: without ground/shell contact, horizontal PCB mount, Retention spring instead of latch The NC3FAH-0 has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm between centres). New designed tulip type contacts with hard gold plating and polished contact areas. UL recognized component.

Product Highlights:

  • Smallest XLR receptacles, highest packing density
  • Plastic housing, steel retention spring
  • Tulip type female contact
  • Polished contact areas and hard gold plating
  • Housing flammability UL94V-0

Search Keywords: NC3FAH0

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Neutrik
Part No:
NC3FAH-0
RoHS:
Yes
HTS:
8536694040
COO:
LI
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide
Number of Contacts:
3
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

IN STOCK: 2,000

Ships today, if you order in

Manufacturer Stock: 3,700   can ship 12/1/25

Minimum Order: 100

Multiple: 100

Factory Lead-Time 3 Weeks can ship 12/11/25

Price (USD)

Qty
Unit Price
100
$1.566
300
$1.504
500
$1.442
1,000
$1.318
2,500
$1.298
5,000
$1.288
7,500 +
$1.277
Suppliers Standard Package
