NC3FD-V
NeutrikD Series - 3 pole female receptacle, vertical PCB mount - Nickel housing - silver contacts Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component. ...
DESCRIPTION
The NC3FD-V is 3 pole female receptacle, vertical PCB mount, Nickel housing, silver contacts The NC3FD-V has rated voltage of < 50 V and rated current per contact of 6 A and dielectric strength of 1,5 kVdc . Universal D-size metal body XLR panel mount series for pcb mount applications. Insert is removable from shell for ease assembling. UL recognized component.
Product Highlights:
- D-shape metal shell
- Optimal RF protection using 3 shield contacts.
- Insert is removable from rear of connector and locked into place by internal latch - permitting assembling and testing of pcb before assembling into housing
- Front or rear panel mount
Search Keywords: NC3FDV
SPECIFICATIONS
IN STOCK: 705
Ships today, if you order in
Manufacturer Stock: 1,700 can ship 12/1/25
Minimum Order: 5
Factory Lead-Time 3 Weeks can ship 12/11/25
Datasheet
