NC3MD-L-1 by neutrik

NC3MD-L-1

Neutrik

DL Series - 3 pole male receptacle - solder contacts, Nickel housing, silver contacts Universal D-size metal body XLR panel mount series. UL recognized component. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NC3MD-L-1 is 3 pole male receptacle, solder contacts, Nickel housing, silver contacts The NC3MD-L-1 has rated voltage of < 50 V and rated current per contact of 16 A and dielectric strength of 1,5 kVdc . Universal D-size metal body XLR panel mount series. UL recognized component.

Product Highlights:

  • Robust "D" metal shell
  • Standardized D sized 24 mm panel cutout
  • Solder cups on 3 - 7 pole version

Search Keywords: NC3MDL1

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Neutrik
Part No:
NC3MD-L-1
RoHS:
Yes
HTS:
8536694040
COO:
HU
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
M
Body Orientation:
Straight
Mounting:
Panel Mount
Housing Material:
Polyamide 6/6
Number of Contacts:
3
Contact Plating:
Silver over Nickel
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

IN STOCK: 1,077

Ships today, if you order in

Manufacturer Stock: 40,600   can ship 12/1/25

On Order: 2,000   can ship 12/29/25

Minimum Order: 5

Factory Lead-Time 3 Weeks can ship 12/11/25

Price (USD)

Qty
Unit Price
5
$5.078
50
$3.945
100
$3.481
300
$3.471
500
$3.451
1,000
$3.430
2,500
$3.420
5,000 +
$3.399
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
