NC5FAH by neutrik

NC5FAH

Neutrik

A Series - 5 pole female XLR receptacle - grounding: separate ground contact to mating connector shell and front panel - horizontal PCB mount The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest si ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NC5FAH is 5 pole female XLR receptacle, grounding: separate ground contact to mating connector shell and front panel, horizontal PCB mount The NC5FAH has rated voltage of < 50 V and rated current per contact of 3 A and dielectric strength of 1,5 kVdc . The 'State of the Art' receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23 mm between centres). New designed tulip type contacts with gold plating of contact area and tin plated pcb termination area.

Product Highlights:

  • Smallest XLR receptacles, highest packing density
  • Plastic housing, steel latch lock
  • Fork type female contact
  • Polished contact areas and hard gold plating
  • Housing flammability UL94HB

Search Keywords: NC5FAH

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Neutrik
Part No:
NC5FAH
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
XLR Connector
Gender:
F
Body Orientation:
Right Angle
Mounting:
Through Hole
Housing Material:
Polyamide 6/6
Number of Contacts:
5
Contact Plating:
AuCo Over NiP15
Termination Method:
Solder
Operating Temperature:
-30 to 80 °C

IN STOCK: 938

Ships today, if you order in

Manufacturer Stock: 18,400   can ship 12/1/25

Minimum Order: 5

Factory Lead-Time 3 Weeks can ship 12/12/25

Price (CAD)

Qty
Unit Price
5
$8.743
50
$7.411
100
$7.059
300
$6.815
500
$6.707
1,000
$6.677
2,500
$6.646
5,000 +
$6.616
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
