NJ3FC6-BAG by neutrik
Image is representational - see manufacturer specifications
NEUTRIK Authorized Distributor

NJ3FC6-BAG

Locking 1/4'' Chassis Jacks - Professional locking 1/4" cable jack for secure in-line connections. Black metal housing - silver contacts - excellent cable protection The 3 pole phone cable jack in-line version provides stable and secure connections wher ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NJ3FC6-BAG is Professional locking 1/4" cable jack for secure in-line connections. Black metal housing, silver contacts, excellent cable protection The NJ3FC6-BAG has rated current per contact of 10 A . The 3 pole phone cable jack in-line version provides stable and secure connections where accidental disconnect or shock and vibration may occur. It latches with standard A-gauge mono or stereo plugs. Plug locks-in automatically when mating and unlocks only by pressing red release tab.

Product Highlights:

  • Securely locking cable jack
  • Mates with all mono and stereo plugs specified acc. EIA RS-453 (A-gauge)
  • Metal shell makes it extremely robust and reliable
  • Neutrik® cable retention and boot as on XLR connectors
  • Solder terminals

Search Keywords: NJ3FC6BAG

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
NEUTRIK
Part No:
NJ3FC6-BAG
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
HU
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
1/4" Phone Jack
Gender:
F
Body Orientation:
Straight
Mounting:
Cable Mount
Housing Material:
Zinc Die Cast
Number of Contacts:
3
Contact Plating:
Silver
Termination Method:
Solder
Operating Temperature:
-20 to 65 °C

IN STOCK: 120

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 3 Weeks

Price (USD)

Qty
Unit Price
5
$12.12
25
$10.32
50
$9.83
100
$9.27
250
$8.69
500
$8.28
1,000 +
$7.86
