NHD-0216K3Z-NSW-BBW-V3

Serial LCD - 2 x 16 Characters - 5V - I2C, RS232, SPI - Controller:PIC 16F690 - TOP 3, 6, 5 Pins ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NHD-0216K3Z-NSW-BBW-V3 is a 2 x 16 Character Serial LCD. It features a STN-Blue Transmissive Display with a White Backlight. Character size is 5.23 x 3.0 mm. It uses an I2C, RS232, SPI Interface. Voltage requirement is 5V. Controller required is the PIC 16F690

Search Keywords: NHD0216K3ZNSWBBWV3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0216K3Z-NSW-BBW-V3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8524919000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BULK
Display Format:
2 x 16 Characters
Display Type:
STN-BLUE
Display Mode:
Transmissive
Text Color:
White
Background Color:
Blue
Backlight:
LED - White
Active Area:
55.65 x 10.98 mm
Character Size:
5.23 x 3.0 mm
Dimension:
80 x 36 x 13.5 mm
Interface:
I2C, RS232, SPI
Supply Voltage:
5 V
Operating Temperature:
-20 to +70 °C

IN STOCK: 170

Can Ship immediately

Manufacturer Stock: 114   can ship 11/2/26

Minimum Order Quantity: 5

Factory Lead-Time 16 Weeks can ship 2/9/27

Price (USD)

Qty
Unit Price
5
$16.53
10
$16.49
25
$16.37
50
$16.24
100
$16.17
250
$16.13
500 +
$16.09
