NHD-0420D3Z-NSW-BBW-V3

Serial LCD - 4 x 20 Character - STN-Blue - White Backlight - 98.0 x 60.0 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NHD-0420D3Z-NSW-BBW-V3 is a 4 x 20 Character Serial LCD. It features a STN-Blue Transmissive Display with a White Backlight. Character size is 4.75 x 2.95 mm. It uses an I2C, RS232, SPI Interface. Voltage requirement is 5V. Controller required is the PIC 16F690

Search Keywords: NHD0420D3ZNSWBBWV3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0420D3Z-NSW-BBW-V3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8524919000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BULK
Display Format:
4 x 20 Characters
Display Type:
STN-BLUE
Display Mode:
Transmissive
Text Color:
White
Background Color:
Blue
Backlight:
LED - White
Active Area:
70.4 x 20.8 mm
Character Size:
4.75 x 2.95 mm
Dimension:
98 x 60 x 13.5 mm
Interface:
I2C, RS232, SPI
Supply Voltage:
5 V
Operating Temperature:
-20 to +70 °C

IN STOCK: 201

Can Ship immediately

Manufacturer Stock: 2,591   can ship 11/2/26

Factory Lead-Time 16 Weeks can ship 2/9/27

Price (USD)

Qty
Unit Price
1
$27.09
5
$23.13
10
$22.97
25
$22.59
50
$22.43
100
$22.37
250 +
$22.11
