NHD-0420DZW-AY5 by newhaven display
Image is representational - see mfr. specs

NHD-0420DZW-AY5

Newhaven Display

Character OLED - 4 x 20 - 5V or 3V - Parallel / 3 wire SPI - Controller:Proprietary - 1 x 16 Top

Datasheet
RoHS Compliant
BULK Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The NHD-0420DZW-AY5 is a 4 x 20 Character OLED. It features a Yellow Display. Character size is 4.75 x 2.90 mm. It uses a Parallel or 3 wire SPI Interface. Voltage requirement is 5V or 3V

Search Keywords: NHD0420DZWAY5

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0420DZW-AY5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8524920000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BULK
Character Size:
4.75 x 2.90
Connector Type:
1 x 16 Top
Backlight:
N/A
Active Area:
70.16x20.95 mm
Dimension:
98 x 60 x 10(Max) mm
Display Format:
4 x 20
Controller:
Proprietary
Back Light (LED):
None
Character Size CH x CW:
4.75 x 2.90
CAGE CODE:
7XUK2

IN STOCK: 907

Can Ship immediately

Manufacturer Stock: 8,944   can ship 7/13/26

Factory Lead-Time 28 Weeks can ship 1/11/27

Price (USD)

Qty
Unit Price
1
$44.35
5
$39.95
10
$39.55
25
$39.17
50
$39.07
100
$38.98
250 +
$38.87
Log in for special pricing Click for Quote Price Match Request
