NHD-0420E2Z-FL-YBW by newhaven display
Image is representational - see manufacturer specifications
Newhaven Display Authorized Distributor

NHD-0420E2Z-FL-YBW

LCD Character Display - 4 x 20 Character - STN-Yellow/Green - Yellow/Green Backlight - 146.0 x 62.5 mm ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NHD-0420E2Z-FL-YBW is a 4 x 20 Character LCD Character Display. It features a STN-Yellow/Green Transflective Display with a Yellow/Green Backlight. Character size is 9.22 x 4.84 mm. It uses an 8-Bit Parallel Interface. Voltage requirement is 5V. Controller required is the KS0066U

Search Keywords: NHD0420E2ZFLYBW

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-0420E2Z-FL-YBW
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8524919000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BULK
Display Format:
4 x 20 Characters
Display Type:
STN- Y/G
Display Mode:
Transflective
Text Color:
Blue
Background Color:
Yellow/Green
Backlight:
LED - Yellow/Green
Active Area:
N/A
Character Size:
9.22 x 4.84 mm
Dimension:
146 x 62.5 mm
Interface:
8-Bit Parallel
Supply Voltage:
5 V
Operating Temperature:
-20 to +70 °C

IN STOCK: 165

Can Ship immediately

Manufacturer Stock: 1,165   can ship 11/16/26

On Order: 115   can ship 12/10/26

Factory Lead-Time 16 Weeks can ship 2/22/27

Price (USD)

Qty
Unit Price
1
$31.83
5
$28.88
10
$26.77
25
$26.51
50
$25.00
100
$24.60
250 +
$24.53
Log in for special pricing
