NHD-C12832A1Z-NSW-BBW-3V3 by newhaven display
Image is representational - see manufacturer specifications
Newhaven Display Authorized Distributor

NHD-C12832A1Z-NSW-BBW-3V3

Chip on Glass- Graphic - 128 x 32 Pixels - 3V - 4-Bit / SPI - Controller:ST-7032 - 17-Pin ...

View Datasheet Ask the Datasheet
RoHS Compliant
BULK Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NHD-C12832A1Z-NSW-BBW-3V3 is a 128 x 32 Pixels Chip on Glass. It features a STN-Blue Transmissive Display with a White 3V Backlight. Character size is / mm. It uses an 4-Bit / SPI Interface. Voltage requirement is 3V. Controller required is the ST-7032

Search Keywords: NHDC12832A1ZNSWBBW3V3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Newhaven Display
Part No:
NHD-C12832A1Z-NSW-BBW-3V3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8524919000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BULK
Display Format:
128 x 32 Pixels
Resolution Standard:
N/A
LCD Type:
STN
Display Mode:
Transmissive
Backlight:
LED - White
Active Area:
31.98 x 7.98 mm
Dimension:
41.4 x 24.3 x 4.9 mm
Interface:
4-Bit / SPI
Supply Voltage:
3 V
Touchscreen:
No
Operating Temperature:
-20 to 70 °C

IN STOCK: 135

Ships today, if you order in

Manufacturer Stock: 1,960   can ship 8/28/26

Minimum Order Quantity: 5

Factory Lead-Time 18 Weeks can ship 12/18/26

Price (USD)

Qty
Unit Price
5
$11.66
25
$9.88
50
$9.22
100
$8.73
250
$8.70
500
$8.68
1,000 +
$8.66
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

NHDEVDEVELOPMENTBOARD

Evaluation Tool for Demonstrating OLEDs, TFTs, Character, Graphic, and COG
