EB2-9TNU by nexem

EB2-9TNU

Nexem

Signal Relay - 9 VDC - DPDT - 1 A - EB2 Series - SMD - 14.3mm x 11.5mm x 7.5mm. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The EB2-9TNU, EB2 series surface-mounting Miniature Signal Relay with compact and light weight. It has three variations of high solder joint reliability type and low profile type. It offers 2-form-C contact arrangement, line-up in minimum footprint (9.3 x 14.3) and high solder joint reliability (20 years) types.

Search Keywords: EB29TNU

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Nexem
Part No:
EB2-9TNU
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Relay Construction:
Latching Double Coil
AC Coil Voltage:
N/A
DC Coil Voltage:
9 V
Contact Arrangement:
DPDT
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Termination Style:
Gull Wing
Coil Current:
15.54 mA
Contact Form:
2 Form C

IN STOCK: 196

Ships today, if you order in

On Order: 1,280   can ship 2/13/26

Minimum Order: 40

Multiple: 40

Factory Lead-Time 15 Weeks

Price (CAD)

Qty
Unit Price
40
$2.037
80
$1.930
160
$1.838
320 +
$1.745
