680M7W2203L201

Name: 680M7W2203L201
Brand: Norcomp
SKU: 49079923
Price: 53.85 USD
Availability: InStock

Female Mixed Contact D-Sub 7W2 Position Straight Solder Cup ...

View Datasheet

RoHS Compliant

DESCRIPTION

The 680M7W2203L201 is a 7W2 female combination D-sub connector designed for mixed power and signal applications using solder cup terminations. It is configured with two 20A power contacts that accept up to 12 AWG wire and five 5A signal contacts that accept up to 20 AWG wire. The connector features a robust design with a steel shell, copper alloy contacts with a full gold flash finish, and a PBT insulator, ensuring reliable performance across an operating temperature range of -55°C to +125°C. This model includes #4-40 clinch nuts on the mating side, making it suitable for secure panel mounting in industrial and telecommunication applications where reliable power and signal connections are critical.

Product Highlights:

Potential Applications:

Search Keywords: 680M7W2203L201

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Norcomp

Part No:

680M7W2203L201

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536694040

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
