Image is representational - see manufacturer specifications
Ohmite Authorized Distributor

TCH35PR470JE

The TCH35PR470JE is a thick film power resistor in a TO-220 package, featuring a 35W power rating, 0.47Ω resistance, and 5% tolerance. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TCH35PR470JE is a thick film power resistor from the TCH series, offering a resistance of 0.47Ω with a ±5% tolerance. Housed in a TO-220 package, it is designed for heat sink mounting and can dissipate 35W of power at a 25°C case temperature. This component features a very low inductance design and a low thermal resistance of <4.28°C/W, ensuring efficient heat transfer. It operates over a temperature range of -55°C to +175°C. Common applications include switching power supplies, snubbers, high-frequency circuits, and voltage regulation.

Search Keywords: TCH35PR470JE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Ohmite
Part No:
TCH35PR470JE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533290000
COO:
AT
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
30
Package Type:
TUBE
Termination Style:
Radial
Power Rating:
35 W
Resistance Value:
470 mOhm
Tolerance:
5 %
Temperature Coefficient:
±150 ppm/°C
Operating Temperature:
-55 to 175 °C
Packaging:
N/A
Dimension:
10.41 x 4.82 x 15 mm
Terminal Pitch:
5.33 mm

IN STOCK: 240

Ships today, if you order in

On Order: 240   can ship 4/5/27

MOQ for In Stock Qty: 30

MOQ for out of Stock Qty: 60

Multiple: 30

Factory Lead-Time 25 Weeks
