TGHGCR0005FE

The TGHGCR0005FE is a 100W, 0.5 mΩ precision current sense resistor featuring a non-inductive design and a four-terminal Kelvin connection. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BOX Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The TGHGCR0005FE is a high-power, precision current sense resistor designed for current monitoring and control applications. It provides a resistance of 0.5 mΩ with a 1% tolerance and has a power rating of 100W at a 70°C case temperature. Housed in a SOT-227 package, this non-inductive resistor utilizes a four-terminal Kelvin connection to isolate the measurement path from the current flow path, ensuring high accuracy. The component operates over a wide temperature range from -55°C to +155°C, making it suitable for demanding industrial environments.

Search Keywords: TGHGCR0005FE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Ohmite
Part No:
TGHGCR0005FE
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533290000
COO:
AT
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Package Type:
BOX
Technology:
Thick Film
Case Style:
N/A
Mounting:
Bolt-On
Power Rating:
100 W
Termination Style:
Screw Terminal
Resistance Value:
.0005 Ohm
Tolerance:
1 %
Temperature Coefficient:
+-250PPM
Military Standard:
N/R

IN STOCK: 109

Can Ship immediately

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
1
$50.15
5
$48.48
10
$34.92
30
$30.53
50
$28.80
100
$26.94
250 +
$24.91
