Z7E by ohmite

Z7E

Ohmite

RF Plate Choke Wirewound 84uH 10% 1KHz 1A 4.7Ohm DCR Solder Lug ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OHMITE Z7E is a high-quality RF plate choke wirewound component designed for optimal performance in a variety of applications. With an inductance of 84uH and a tolerance of 10%, this choke is perfect for use in RF circuits to reduce unwanted frequencies and enhance signal integrity. The component is capable of handling a maximum current of 1A and features a 4.7Ohm DCR (Direct Current Resistance) to ensure efficient power transmission. The Z7E model is equipped with convenient solder lug terminals, simplifying the installation process and providing a secure connection. Whether you are working on a professional audio system, radio transmitter, or any RF application, the OHMITE Z7E provides reliable and consistent performance.

Search Keywords: Z7E

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Ohmite
Part No:
Z7E
RoHS:
Yes
HTS:
8504500000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
BOX
Inductance:
84 uH
Type:
RF Plate Choke
Impedance:
N/A
Lead Pitch:
N/A
Tolerance:
10 %
Technology:
Wirewound
Maximum DC Resistance:
4.7 Ohm
Maximum DC Current:
1 A
Protection Style:
N/A
Packaging:
N/A

IN STOCK: 285

Can Ship immediately

Manufacturer Stock: 11   can ship 12/1/25

Factory Lead-Time 11 Weeks can ship 2/4/26

Price (USD)

Qty
Unit Price
1
$36.905
5
$34.690
10
$33.743
25
$32.486
50
$31.528
100
$28.150
250 +
$24.648
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides
