DZ10GW1B by omron automation

DZ10GW1B

Omron Automation

Basic switch - hinge lever - 10 A - DPDT - screw terminals ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OMRON INDUSTRIAL part DZ10GW1B is a high-quality snap action switch designed for industrial applications. With a double-pole, double-throw (DPDT) configuration, it provides both normally open (N.O.) and normally closed (N.C.) contacts for versatile control options. This switch features a hinge lever for easy actuation and is capable of handling a maximum current rating of 10A at 250VAC or 250VDC, with a power rating of 186.42VA. Its screw mount design ensures secure and reliable installation. The DZ10GW1B switch from OMRON INDUSTRIAL is a durable and reliable solution for various industrial control applications.

Search Keywords: DZ10GW1B

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Automation
Part No:
DZ10GW1B
RoHS:
Yes
HTS:
8536507000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Through Hole
Pole Throw Configuration:
DPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Stainless Steel/Hinge Lever
Contact Rating @ Voltage:
186.42@(CSA/UL) A
Maximum Movement Differential:
4 mm
Operating Force:
1.67 N
Termination Style:
Screw
Dimension:
72.4 x 17.45 x 54.5 mm
Body Orientation:
Straight
IP Rating:
IP00

IN STOCK: 308

Ships today, if you order in

Factory Lead-Time 36 Weeks

Price (CAD)

Qty
Unit Price
1
$65.326
5
$58.204
25
$50.411
50
$48.542
100
$47.531
250
$46.583
500 +
$46.352
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
