B3U-1000P by omron electronics
Image is representational - see mfr. specs

B3U-1000P

Omron Electronics

Switch Tactile N.O. SPST Round Button Gull Wing 0.05A 12VDC 1.5N SMD T/R ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The B3U-1000P is a single-pole single-throw (SPST) SMD ultra-small Tactile Switch with black plunger and top-actuated operation. This switch features NO contact action. This compact switch allows high-density mounting on PCBs for mobile equipment. The dust-proof construction provides high reliability in dusty environments. It is surface mounted which is ideal for high-density mounting. High contact reliability 100mΩ Maximum initial contact resistance 100MΩ at 100VDC Minimum insulation resistance 5ms Maximum bounce time 1000m/s² Maximum shock resistance 200000 operations Minimum durability Applications Industrial

Search Keywords: B3U1000P

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
B3U-1000P
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509065
COO:
JP
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
3500
Package Type:
Reel
Dimension:
4 x 2.5 x 1.6 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
N.O.
Actuator Style:
Round Button
Operating Force:
1.5 N
Contact Rating @ Voltage:
0.05@12VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
Gull Wing
Seal Location:
N/A

IN STOCK: 15,976

Can Ship immediately

On Order: 21,000   can ship 2/15/27

Minimum Order Quantity: 500

Factory Lead-Time 45 Weeks

Price (USD)

Qty
Unit Price
500
$0.593
1,000
$0.582
3,500
$0.553
7,000
$0.551
10,500
$0.548
17,500
$0.545
28,000 +
$0.543
Reel Package
Log in for special pricing Click for Quote Price Match Request
